2AZ-FE 2.4L Engine Rebuild Kit Crankshaft Timing Chain Head Gasket 13401-28030

2AZ-FE 2.4L engine rebuild overhaul kit. New, complete set.

This is an aftermarket rebuild kit. It is not manufactured by Toyota.

Fitment, 2AZ-FE engine only
Toyota Highlander 2.4L, 2001 to 2007
Toyota Solara 2.4L, 2002 to 2008
Toyota Camry 2.4L, 2002 to 2009
Toyota RAV4 2.4L, 2004 to 2007
Toyota Corolla XRS 2.4L, 2009 to 2010
Toyota Matrix 2.4L, 2009 to 2011
Scion tC 2.4L, 2005 to 2010
Scion xB 2.4L, 2008 to 2015

Does not fit the 2AZ-FXE hybrid engine.

Replaces
Crankshaft: 13401-28030, 13401-28900, 13401-28010
Connecting rods: 13201-29685-A0, 13201-29685-B0, 13201-29685-C0, 13201-29125-A0, 13201-29125-B0, 13201-29125-C0
Piston rings: 13011-0H031, 13211-0H041-A0, 13211-0H041-B0, 13211-0H041-C0, 13251-0H030-B0, 13251-0H030-C0
Bearings: 13281-28010, 13281-28011, MB5646SI, MB922, BM15-104, MBTO44, CR4514SI, RB922, BB1001, RBTO44, BR15-104
Head gasket set: 11115-28010, 11115-28011, 11115-28012, 11115-28013, HS26232PT
Cover gasket: 11213-0H040, 11213-28021
Manifold gasket: 17173-0H020, 17173-0H040
Head bolts: ES71183
Seals: 90080-31072, 90311-38078, 90311-38080, 90311-T0024, 90311-38089, 90311-38096, 90311-A0014
Timing chain kit: 13523-0D010, 13521-0H010, 13506-0H011, 13540-0H010, 13561-0H010

Before you order, read this

Check your block for stripped head bolt threads. The 2AZ-FE is known for pulling head bolt threads out of the aluminum block, and Toyota issued a warranty enhancement over it. If your threads are damaged, the block needs M11x1.5 thread inserts installed before any gasket kit will hold. No head gasket set fixes a stripped block.

This is a full rebuild, not a bolt-on job. Plan on machine shop work: check the crank journals, bore and hone the block, and resurface the head. Measure your bearing clearances rather than assuming standard.

Verify the head bolt length against factory spec before assembly. Torque the head in the correct sequence and to the correct spec, in stages.

Confirm your engine code is 2AZ-FE before ordering.

ADDITIONAL INFORMATION FOR VERIFICATION:
Type: Engine Rebuild Kit
Manufacturer Part Number: 13401-28030
Interchange Part Number: 1340128030, 2AZ, 2AZ-FE, 2AZFE, 10369859
OE/OEM Part Number: 13401-28900, 13401-28010, 13201-29685-A0, 13201-29125-A0, 13011-0H031, 13211-0H041-A0, 13281-28010, HS26232PT, ES71183
Engine Code: 2AZ-FE
Engine Size: 2.4L, 16V DOHC VVT-i
Compatible Vehicle Make: Toyota, Scion
Compatible Vehicle Model: Camry, Highlander, RAV4, Solara, Corolla XRS, Matrix, tC, xB
Items Included: Crankshaft, Timing Chain Kit, Head Gasket Set
Placement on Vehicle: Front
Country of Origin: China
Condition: New
